SM-GAP-102 (500 KG) – Facade Cleaning System Technical Specifications
The SM-GAP-102 is a powerful system designed for safe and efficient facade cleaning operations on high-rise buildings. With a lifting capacity of 500 kg, this model can easily handle heavy loads while prioritizing user safety through advanced safety systems. Thanks to its technical features, it delivers high performance and long-lasting operation.
➤ Lifting Capacity: 500 kg
➤ Motor Power and Quantity: 2 x 1.1 kW
➤ Climbing Speed: 0.15 m/s
➤ Platform Dimensions (m): 2 m
➤ Safety Systems: Electromagnetic brake / 2 block-stop brakes
➤ Rope Diameter: 8 mm (6x19) Galvanized
➤ Rope Winding Mechanism: 2 units
➤ Voltage: 380 V
SM-GAP-102 – Safety Measures
The SM-GAP-102 model prioritizes safety at every stage, ensuring that users can operate with maximum security. Thanks to its advanced safety features, the system can stop and function safely in any unexpected situation. This model is equipped with special systems for emergency situations and power outages.
➤ Emergency Stop Switch: 1 unit (Red marked)
➤ Manual Lowering System in Case of Power Failure: (Red marked)
➤ 2 Block-Stop Mechanisms in Case of Rope Failure: (Red marked)
➤ Tilt Sensor: Limited to 14 degrees inclination (Red marked)
➤ Upper and Lower Limit Switches: (Red marked)
➤ Overload Detection System: (Red marked)
